Warn Land Rover Winches

The new face of Land Rover winches are here – so say Warn Winches. A bold statement, but their position as the top choice for heavily-loaded off-road vehicles is one well earned. Their new winches cover a number of ranges designed to appeal to users of different strokes – whether it’s for industry and domestic use, their winches have more than enough muscle to manage your task.

Image Copyright Warn Industries Inc.

Warn Land Rover Winches – Like Nothing You’ve Ever Seen Before:

Warn’s winches range from the entry level ‘Tabor’ series up to their premium ‘Zeon’ winch, let’s take a look at two of them:

Warn Tabor 8000 12V 8000LB Winch:

The Tabor 8K has a full 8,000 lb. pulling capacity that makes this winch ideal for lighter land rovers. Quick line speed, durable construction, and WARN dependability ensure this winch will come through time and time again.

Legendary WARN reliability and performance; 8,000 lb. (3630 kg) capacity
Low-profile design will fit most trucks and SUVs
Separate control pack for various mounting options
Exclusive brake design for superior winching control
Durable, smooth, and reliable three-stage planetary geartrain
Series-wound motor for power and fast line speed
Remote control with 12’ (3.7m) lead
94’ of 5/16” (28.6m of 8mm) diameter wire rope

SPECIFICATIONS:
Winch model: Tabor 8K
Part number: PN 88390 (12V)
Rated line pull: 8,000 lbs., (3629 kg) single-line
Motor: 12V DC Series Wound
Electrical controls: Solenoid
Remote Control: Remote switch, 12’ (3.7m) lead
Geartrain: 3-Stage Planetary
Gear ratio: 216:1
Clutch (freespooling): Sliding Ring Gear
Brake: Automatic Direct Drive Cone
Drum diameter/Length: 2.5”/9.0” (6.4cm/23cm)
Weight: 80 lbs. (36.3 kgs)
Wire Rope: 94’, 5/16”diameter (28.6m, 8mm diam.)
Fairlead: Roller
Recommended Battery: 650 CCA minimum for winching
Battery leads: 25mm2 wire, 72” (1.83m)
Finish: Powder coat

At the other end of the spectrum we have the Zeon 12:

Warn Zeon 12 12000LB 12V Winch:

The WARN ZEON 12 is the new face of winching. Bolt one on, and you’ll be ready for anything.
A top choice for those with heavily-loaded off-road vehicles, the ZEON 12 features innovative design, increased performance and durability, steel rope, and a hefty 12,000 lb. single-line pulling capacity. The ZEON 12 is a pulling machine you can rely on to rescue you-or your buddies, from nearly anything.

12,000 lb. (5443 kg) single-line pulling capacity.
Includes 80′ of durable 3/8″ galvanized steel wire rope.
Convertible control pack can be attached to the winch or remotely mounted, allowing for various winch mounting options and looks (Relocation kit required and sold separately*).
Gear train and motor deliver reliable pulling power that is fast, and quieter than ever.
Satin-black powder-coated finish with stainless steel fasteners and clutch lever looks great and inhibits corrosion. Improved winch sealing to keep the elements out.
Large diameter winch drum reduces rope wear, is light weight, and has an integrated rope anchor for easy rope installation.
Backed by the WARN Limited Lifetime Warranty.
Control Pack Relocation Kit. Required to mount control box remotely from winch. PN 89970 (Short kit), PN 89960 (Long kit).

SPECIFICATIONS:
Part number: 89660
Rated line pull: 12,000 lbs. (5443 kg) single-line
Motor: 12V DC, series wound
Electrical controls: Contactor
Remote Control: Remote switch, 12′ (3.7m) lead
Geartrain: 3-stage planetary
Gear ratio: 216:1
Clutch (freespooling): Rotating ring gear
Brake: Automatic mechanical cone
Drum diameter/Length: 3.15″/9.0″ (80mm/229mm)
Weight (kit shipping): 98 lbs. (44 kg)
Rope: 3/8″ x 80′ (9.52mm x 24.38m) steel
Fairlead: Roller
Recommended Battery: 650 CCA minimum for winching
Battery leads: 2 gauge, 72″ (1.83m)
Finish: Satin-black powder coat
Warranty: Limited lifetime

Powerful stuff, to be sure. Curious to try for yourself? Click here to see our full range of Warn Land Rover winches. We’re always happy to help with any enquiries, so feel free to get in touch, or leave a comment below!
